Build JHipster Microservices and | The JHipster Mini-Book

JHipster has the ability to generate a microservices architecture. A typical microservices architecture is composed of a registry and config server, a gateway, 1-many microservice applications, and a monitoring application. The diagram below shows the open source components that JHipster uses.

Diagram

Last week, I spent an evening recording a screencast of how to generate a microservices architecture using the following steps:

Convert blog demo app from a monolith to a gateway by changing .yo-rc.json to the following values and running yo jhipster --with-entities.
```
hibernateCache: "hazelcast"
serviceDiscovery: "eureka"
applicationType: "gateway"
```
Create a "store" microservices app with MongoDB and generate a product entity.
Create a UI for the product entity in the gateway app using yo jhipster:entity product.
Clone the JHipster Registry in a parallel directory to apps, start everything (using Docker Compose for MongoDB) and prove it all works.
Create a k8 directory alongside apps and run yo jhipster:kubernetes.
Create a Google Cloud project at console.cloud.google.com.
Install Google Cloud SDK and set project using gcloud config set project $project-name.

Create a cluster:

gcloud container clusters create demo --machinetype=n1-standard-2 --scopes cloud-platform

Run kubectl commands to deploy.
Use port-forwarding to see the registry app locally.
```
kubectl port-forward jhipster-registry-0 8761:8761
```

Scale microservice apps as needed:

kubectl scale deployment store —replicas=3

I recorded a screencast of this process and published it to YouTube.

I also attended Devoxx US last week and spoke about What's New in JHipsterLand. You can see the slides from my talk below. The source code for the microservices demo I did is available on GitHub.

The next JHipster talk I'll be doing will be at Devoxx UK. Until then, stay hip my friends!

Update: Devoxx US has posted a video of What's New in JHipsterLand on YouTube. You might notice I have a black eye in this video. That's from skiing the trees at Northstar and getting nipped by a branch the weekend before. It was so warm, I wore sunglasses instead of goggles. Doh! 🤕
